Factory customzied dongfeng 7m3 garbage compactor truck with rear wastes bins overturning mechanism for sale,
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of garbage trucks, such as garbage compactor truck, refuse garbage truck, side loader garbage truck, swing arm garbage truck, rear loader garbage truck, hook lifter garbage truck, etc. More information, please feel free to contact with Ms. Anita Deng.
The technical parameters of DONGFENG brand garbage compacted truck as below
1. Trash body capacity: 6-7m3
2. Using electronic accelerator;
3. Dozer cylinder have new features for automatic withdrawal;
4. Using Siemens operation circuit;
5. Slider uses the high polymer wear-resistant material;
6. simple structure, convenient operation, high efficiency and high degree of mechanization and labor-saving.
7. Factory direct sale, low price and good quality.
Control way of the garbage compactor truck manufactured by Chengli Special AUtomobile Co., Ltd. as below:
The volume of the compactor garbage van is 10m3, adopting high quality China standard light duty steel, solid arc-shape box body of strengthen beam and steel plate weled.
Operation way: PLC control system; loading and discharging way: rear loading wastes bins mechanism; compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; one working circle time for loading and discharging ≤30s; max compressing force≥150KN; max passing force≥180KN.
If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat: +86 13329899995.
Website: www.trucksinchina.com
More pictures of hot sale dongfeng 7m3 garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd. as below.
high quality and competitive price dongfeng 7m3 garbage compactor truck for sale
HOT SALE! 7m3 compacted garbage truck for sale
If you're interested in our garbage compactor trucks, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
main technical parameters of hot sale dongfeng 4*2 7m3 garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd. as below
| [Main Technical Parameter] |
| Product Name | 7m3 garbage compactor truck for sale |
| Gross Weight (Kg) | 7490 | Capacity(kg ) | 5000kg |
| Rated Payload(Kg) | 1200 | Overall Dimension(mm) | 7000X2320X2900 |
| Curb Weight(Kg) | 6095 | Cab Allowed Person | 3 |
| App./Dep.(°) | 20/11 | F/R Suspension(mm) | 1180/2020 |
| Axle No. | 2 | Wheelbase(mm) | 3800 |
| Axle Load(Kg) | 2845/4645 | Max Speed(Km/h) | 95 |
| [Chassis Technical Parameter] |
| Chassis Model | EQ1070 | Chassis Brand | DONGFENG |
| Overall Dimension(mm) | | Tyre No. | 6 |
| App./Dep.(°) | 20/11 | Tyre Specification | 7.00R16 |
| Spring Leaf No. | 11/9+7 | Front Track(mm) | 1835 |
| Fuel Type | Diesel | Rear Track(mm) | 1640 |
| Brake | Air b rake with power steering | Transmission | 5 speed transmission |
| Driver cab | RHD single row driver cab | bridge | 2.4ton front bridge/4.2ton rear bridge |
| Emission Standard | Euro 3 |
| Engine Model | CY4102-E3C | Manufacturer | Chaochai |
| Displacement(ml) | 3856 | Power | 91/120hp |
| Cylinder No. | 4 cylinders in line | Engine Type | Vertical 4 strokes, 4 cylinders in line, Water cooling, inter-cooling diesel engine, |
Equipment: 1. Equipped with completely sealed dustbin, hydraulic system, operation system.
2. Equipped with rear turnover Manichaeism can hook dustbin or loading garbage by itself.
3. Equipped screeds and push shovel, compress by itself. High compression ratio. The sewage
Will flow to sewage tank automatically, avoid second pollution.
4. Good sealed performance, easily operation, and high safety. |
More information, please feel free to contact with Ms. Anita.
Whatsapp/Wechat/Mob.:+86 13329899995
Skype: truck0011
QQ: 504873236
|
|
