Chengli brand factory direct sale 3 axle 48700L 26 ton anhydrous ammonia lpg transport trailer with cheapest price
Brief introduction of anhydrous ammonia lpg transport trailer
The anhydrous ammonia lpg transport trailer is also called lpg trailer, lpg gas tanker trailer, liquid gas trailer,ammonia transport trailer, anhydrous ammonia semi trailer, lpg transportation trailer,etc. It is mainly used to transport lpg gas, such as propane, liquid ammonia,
etc.
Chengli anhydrous ammonia lpg transport trailer for sale are made of lpg gas cylinder special
material, they are Q345R or Q370R . It is equipped with pressure gauge,safety relief valve,
emergency brake valve, thermometer,inspection manhole,drain valve, toolbox,etc.
We, Chengli Special Automobile Co.,Ltd is a professional anhydrous ammonia lpg transport trailer manufacturer in China. We are a real lpg tank trailer factory, lpg tank truck factory, lpg storage tank factory.
The lpg tank we produce is from 5m3 to 120m3
The liquid gas trailer for sale is from 40.5m3 to 59.52m3
The lpg gas truck we produce is from 5m3 to 35.5m3
The production processing and inspection of CLW lpg tank is very strict. Our lpg tank is 100% x-ray test , hydraulic test and export over all the world. The service time of our lpg tank is more than 15 years.The semi-trailer axles can be FUWU brand, BPW brand,etc. The tyres can be steel wire tyre, tubeless tire, Nylon tyre. The landing leg of our semi-trailer can be Jost brand, FUWA brand,etc. The kingpin diameter of our semi-trailer can be 90mm or 50mm.
More information, please feel free to send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat: +86 13329899995
More pictures of hot sale 26tons lpg gas trailer for ammonia as below.
lpg gas trailer with sunshield cover for sale
bulk lpg gas trailer for ammonia for sale
Technical Parameters of 26 ton anhydrous ammonia lpg transport trailer
| GENERAL DESCRIPTION |
| Vehicle Product | Anhydrous ammonia tanker semi trailer |
| Vehicle Brand | CLW |
| Overall Dimension | 12460x2500x3880mm(L x W x H) |
| GVW./Kerb Weight | 40000Kg/14189Kg. |
| Loading Weight | 25811kg |
| TANK BODY |
| Tank Volume | 48700 liters |
| Tank Material | Q345R |
| Cylinder Body | 8mm thick |
| Head Type & Thickness | spherical, 8mm |
| Loading Medium | Anhydrous ammonia |
| Design Pressure | 1.91MPa |
| Loading coefficient | 0.95 |
| CHASSIS |
| Heavy duty reinforced chassis with reinforced axle. The tank’s framework consists of two fabricated steel beams of high quality 16 Manganese steel. The two beams are fully welded all over their length on the tank. The beams are strongly connected with the cross members supporting the suspension and the kingpin upper coupler. |
| RUNNING GEAR |
| Trailer Axles | BPW/FUWA brand,etc. 3x13ton axles with double wheels |
| Landing Legs | JOST/FUWA brand,etc. 28tons per pair |
| Suspension System | Steel spring suspension or air bag suspension |
| King Pin | JOST/FUWA brand,etc. 2inch or 3.5inch,bolted and welded type are optional |
| Tyre No.&Spec. | 12 tires,11.00R20 steel wire tire |
| MUDGUARDS |
| Heavy duty mudguard rubber mud-flaps |
| BUMPERS |
| Side bumpers mounted between landing gear and first axle, rear bumper is European standard |
| ELECTRIC SYSTEM |
| 24V lighting system,electrical socket for lighting,rear lamp with parking,direction,fog,reverse, 4 side lights |
| PAINTING |
| All steel plates and structure are blasted first, then painted with two anti-corrosive primer coats and two lever top. |
| OTHER BASIC EQUIPMENT |
| Safety valve, thermometer, pressure gage, emergency cut-off valve, fire extinguisher, anti-static rope |
More information, please feel free to contact with Ms. Anita.
Whatsapp/wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
|
|
Chengli brand 3 axles 48700L 26 ton anhydrous ammonia lpg transport trailer with sunshield cover, ammonia tank trailer Images
|
