Customized dongfeng D9 4*2 13cbm 230hp diesel garbage compactor truck for sale,best seller new face 12cbm compacted garbage truck for sale
Customized dongfeng D9 4*2 13cbm 230hp diesel garbage compactor truck for sale adopts dongfeng D9 one row and a half luxurious driver cab, 4500mm wheelbase, 8 speed gearbox, 5tons front axle/10tons rear axle, 10.00R20 rail tires*6, B6.2NS6B230 Cummins 230hp diesel engine, etc.
The volume of dongfeng D9 compression garbage truck is 12cbm-13cbm.
main technical parameters of dongfeng D9 13cbm garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| 1 | Product name | Dongfeng 4*2 LHD 13m3 garbage compactor truck (CLW5180ZYS6) |
| 2 | Truck chassis model | EQ1185 |
| 3 | Overall dimension(L*W*H) | 8350×2550×3300 |
| 4 | Total mass(kgs) | 18000 |
| 5 | Curb mass(kgs) | 9700 |
| 6 | Rated mass(kgs) | 8170 |
| 7 | Volume | 13m3 |
| 8 | Max speed | 105kw/h |
| 9 | Wheelbase | 4500 |
| 10 | Axle nos. | 3 |
| 11 | Driver cab | dongfeng D9 one row and a half luxurious driver cab |
| 12 | Approach/departure angle(°) | 19/12 |
| 13 | Front/rear suspension (mm) | 1260/2390 |
| 14 | Front/rear tread(mm) | 1862/1800 |
| 15 | Tire specification | 10.00R20*10+1 |
| 16 | Steel Spring | 8/10+7 |
| 17 | Engine model | B6.2NS6B230 |
| 18 | Rated power | 169KW/230hp |
| 19 | Displacement(ml) | 6200ml |
| 20 | Fuel type | Diesel |
| 21 | Emission standard | Euro Ⅵ |
| 22 | Gearbox | 8 speed gearbox, manual |
| 23 | Front/rear axle | 5tons front axle/10tons double rear axles |
| 24 | Color | Different color upon request |
| 25 | Wastes van | Solid arc-shape box body of strength beam and steel plate welded |
| 26 | Wastes van material | High quality China standard light duty steel |
| 27 | Operation way | PLC control way |
| 28 | Loading and discharging way | Rear overturning mechanism |
| 29 | Compacted way | Bi-directional compression |
| 30 | Wastes compacting density | ≥0.8tons/m3 |
| 31 | One working circle time for loading and discharging | ≤30s |
| 32 | Color | White color upon request |
If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com .
More pictures of new designed dongfeng D9 13cbm compacted garbage truck as below.
s a professional compactor refuse truck manufacturer in China, we have dumper garbage truck, refuse compactor garbage truck, arm roll garbage truck, hook lifter waste truck, side self-loading garbage truck, etc.
The refuse compactor truck is usually called compactor garbage truck,garbage compactor truck, compacted garbage truck,compressed refuse truck, waste compactor truck, etc.
Our trash truck compactor is constructed with 12# low alloy steeland 5mm, 4mm, 10mm steel.The body is fitted on the chassis by the truck beam.The body floor is fully sealed.All the sewage can go directly into the sewage tank,so as not to corrode the body and chassis .Moreover,it can also prevent the sewage leakage while the truck is driving on the road and avoid the secondary pollution.
The refuse compactor truck for sale usually compacts the waste using a hydraulically powered mechanism that employs a moving plate or shovel to scoop the waste out from the loading hopper and compress it against a moving wall. In most compactor designs, the plate has a pointed edge (hence giving it the industry standard name packer blade) which is designed to apply point pressure to the waste to break down bulky items in the hopper before being drawn into the main body of the truck.
There are three kinds of mechanism options available to the customer,barrel turnover mechanism,panel turnover mechanism and tipping mechanism.by the use of hydraulics,the barrel is locked during the overturning process,which is very safe and reliable.
As a professional compression garbage truck manufacturer in China, with ISO9001-2008 quality system and 3C certificate, the trash compactor trucks we produce is from 4m³ to 18m³. The mini trash compactor for sale is 4 cubic meters.
|
|
Customized dongfeng D9 13cbm 230hp diesel garbage compactor truck for sale,best seller 12cbm compacted garbage truck Images
|
